Side Panels
A side panel of the device follows:
Not all models have a GPS connector.
The figure that follows shows the other side of the device.
Ethernet LED Descriptions
Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs.
Ethernet Link
®
MultiConnect
rCell 100 Series Router User Guide
Right LED on Ethernet connector. Blinks when there is transmit and
receive activity on the Ethernet link. It shows a steady light when
there is a valid Ethernet connection.
PRODUCT OVERVIEW
7
