Power Draw

Radio Protocol Cellular Cell Box
Connection No Data
(Amps)
7.0 Volts
GSM 850 MHz 0.239
HSDPA N/A
9.0 Volts
GSM 850 MHz 0.206
HSDPA N/A
32.0 Volts
GSM 850 MHz 0.067
HSDPA N/A
Note: Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load. The above power draw numbers are measurements from an MTR-H5-B10.

RF Specifications

Mode
GSM850
EGSM900
DCS1800
PCS1900

Additional RF Specifications

Mode
WCDMA800 *
(Band VI)
WCDMA800 *
(Band XIX)
®
MultiConnect rCell 100 MTR-H5 User Guide
(AVG) Measured
Current (Amps) at
Max Power
0.589
0.797
0.315
0.606
0.151
0.185
Frequency TX (MHz) Frequency RX (MHz) Channels
824 to 849 869 to 894
890 to 915 935 to 960
880 to 890 925 to 935
1710 to 1785 1805 to 1880
1850 to 1910 1930 to 1990
Frequency TX (MHz) Frequency RX (MHz) Channels
830 to 840 875 to 885
830 to 845 875 to 890
CHAPTER 1 PRODUCT OVERVIEW
TX Pulse (AVG)
Amplitude Current
(Amps) for GSM850 or
Peak Current for
HSDPA)
1.67
0.808
1.06
0.624
0.356
0.188
128 to 251
0 to 124
975 to 1023
512 to 885
512 to 810
TX: 4162 to 4188
Additional: 812, 837
RX: 4387 to 4413
Additional: 1037, 1062
TX: 312 to 363
Additional: 387, 412, 437
RX: 712 to 763
Additional: 787, 812, 837
Total Inrush Charge
Measured in
Millicoulomb (mC)
2.09
N/A
1.86
N/A
0.720
N/A
TX - RX Offset (MHz)
45
45
45
95
80
TX - RX Offset
45 MHz
45 MHz
