A – Specifications

Maintainability

Buffer Credits.................................. 12 buffer credits per port
Media Type ..................................... Small Form Pluggable (SFP) optical
Fabric Port Speed ........................... 1.0625 or 2.125 Gigabits/second
Maximum Frame Size..................... 2148 bytes (2112 byte payload)
System Processor........................... 266 MHz Pentium® processor
Fabric Latency (best case) ............. <0.4 µsec.
Fabric Point-to-Point Bandwidth ..... 212 or 424 MB/s full duplex
Fabric Aggregate Bandwidth .......... 64 Gb/s for a single switch
A.2
Maintainability
Maintenance Strategy ..................... Field Replaceable Units
Diagnostics ..................................... Power On Self Test (POST) tests all
User Interface ................................. LED indicators
A-2
transceivers. Hot swappable. 3.3 Volts.
SFP transceivers
Power supplies
Fans
functional components except SFP
transceivers. Port tests include online,
internal, and external tests.
D
59021-07 A
