This section describes the features and capabilities of the SANbox2-16 Fibre
Channel switch. The following topics are described:
Fabrics are managed with the SANbox Manager switch management application
(version 3.00) and the Command Line Interface (CLI). Refer to the
SANbox2-8c/16 Switch Management User's Guide for information about using the
SANbox Manager application. Refer to
more information about the command line interface.
59021-07 A
General Description
Chassis controls and LEDs
Fibre channel ports
Ethernet port
Serial port
Power supplies
Fans
Switch management
Figure 2-1. SANbox2-16 Fibre Channel Switch
Section 2
Appendix B Command Line Interface for
2-1
