Chapter 4 . Hardware Assembly

The Inventor comes pre-assembled and is almost ready-to-print (ARP). All you need
to do is set the appropriate voltage, mount the extruder set, and install the filament. It
will only take between 5 to 10 minutes before you can fire up the Inventor and
prepare for your first 3D print!

4.1 Mounting the Extruder Set

4-1
(4-1) Lay the extruder set on top of the extruder seat with the two extruder fans facing
the front.
4‐2
(4-2) Secure the extruder set onto the extruder seat by using two M3x12 from the
bottom up.
