SZ15-ZN/EN-A04
Quick Start Guide
快速启动指南
1. Hot! Avoid touching the heating nozzle and heating build plate in operation.
2. Moving parts in printer may cause injury. Do not wear gloves or other
sources of entanglement in operation.
Download
Please refer to FlashForge official website www.flashforge.com to download
the newest User's Guide, Software and Instruction Videos.
(Support-Support Center-Select a Product)
1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!
2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。
资料下载
前往闪铸科技官方网站 www.sz3dp.com ，可以在[ 技术支持 ] 页面下载用户使
用手册、切片软件等资料，或查看相关操作视频。
中文
Advertisement
Related Manuals for Flashforge Inventor II
Summary of Contents for Flashforge Inventor II
- Page 1 2. Moving parts in printer may cause injury. Do not wear gloves or other sources of entanglement in operation. Download Please refer to FlashForge official website www.flashforge.com to download the newest User's Guide, Software and Instruction Videos. (Support-Support Center-Select a Product) 1.
- Page 2 Grease / Allen Wrench...
- Page 3 10. Leveling Knob...
- Page 4 1. Take out the packing box, which contains a Quick Start Guide, a After-sales Service Card, a power adapter, a power cable, a solid glue, a filament guide tube, a tool bag with an USB stick inside.
- Page 6 5. Connect power adapter with the power cable and then insert the power supply into the power input on the back of the Inventer II. Turn on the power switch and press the touch screen button to turn on the printer.
- Page 7 Screw the three nuts under the platform counterclockwise until they are tight, then tap the [OK] button. 1. Tap [Tools]-[Level] on your InventorII touch screen. Please wait while the extruder and platform finish initial movements. Screw three nuts under the platform counterclockwise, then tap [OK] button.
- Page 8 2. After tapping [OK] button, the extruder will move towards the first point and the plate will move up and down to verify the distance between nozzle and plate. Turn the corresponding nut under Turn the corresponding nut under the platform clockwise until the platform counterclockwise until you hear the beep.
- Page 9 1. Tap [Preheat]--[Start] to heat up the extruder. 2. Once preheated, hold down the spring presser and pull out the filament. 3. Tap the return button, insert the new filament into the filament intake, tap [Tools]-[Filament]- [Load]. The filament will be drawn through the extruder once heated. Wait for the extruder to provide a steady flow of filament.
- Page 11 润滑脂 / 内六角扳手...
- Page 12 触摸屏 触摸屏开关 电源线接口...
- Page 13 1. 打开纸箱取出中间的包装盒，上方自封袋内 有快速启动指南和售后服务卡，盒内含有电 源线、USB线、电源适配器、工具包（内有 U盘等工具）、固体胶和导丝管。...
- Page 14 10. 用手托住打印平台，缓缓将其提升， 以便于取出平台下方的泡沫盒。...
- Page 16 请逆时针拧紧底板下三个螺母 再点击【确定】按钮。 1. 点击触摸屏上【工具】－【调平】图标，待喷头和打印平台完成初始化运动后逆时针拧紧底板 下三个螺母，再点击【确认】按钮。...
- Page 17 2. 喷头开始移向第一个点，打印平台上下移动来验证喷嘴与平台之间的距离。 顺时针调节平台下对应的螺母 逆时针调节平台下对应的螺母 直到听到持续稳定的提示声。 直到听到持续稳定的提示声。...
