1.4.1 SEVEN RECEIVER SCREEN SYMBOLS

The following symbols may appear on the Receiver display during use:
AntennA: If seen in the bottom right corner of
Glucose Trend Screens, the Y indicates that the Receiver
and Transmitter are "talking" and glucose data has been
sent in the last 5 minutes
Low BAttery ALert: Indicates the Receiver battery
is running low and needs to be recharged. Charge the
battery as soon as possible.
ConneCtion: Indicates the OneTouch Ultra meter
is successfully transferring readings to your Receiver via
Auto-Upload with the Connection Cable.
ConneCtion FAiLure: Indicates the OneTouch
Ultra meter and your Receiver are not connected
properly. Readings have not been successfully
transferred. This screen will only be seen when you
attempt to use the Connection Cable.
new Meter SCreen: Indicates that a new OneTouch
Ultra meter has been plugged into the Receiver. This
meter has a different serial number from the meter that
was last connected to the Receiver. If you receive this
screen during auto-upload calibration, you will have to
re-take any fingersticks needed for calibration and then
connect the 2 devices again for calibration update.
Seven System User's Guide | 23
™
