TIME-ELAPSED PLOTS
Examples of Seven Continuous Glucose Monitoring System overlaid with the
corresponding YSI readings over time are presented below. The horizontal axis represents
time, with the matching Seven System and YSI readings plotted above the point in time
when the measurements were taken. The circles ( ) on the graph represent the Seven
System data, connected by a line. The "Y" represents the YSI reading.
There are three Figures presented. Figure 2 is an example of when the Seven System
performed well, Figure 3 represents a period when the Seven System performed in an
average manner, and Figure 4 represents when the Seven System performed poorly.
