Dynacode series
Error message
1 Line too high
2 Line too low
3 Character set
4 Unknown code type
5 Unvalid position
6 CV font
7 Vector font
8 Measuring label
9 No label found
10 No ribbon
11 COM FRAMING
12 COM PARITY
13 COM OVERRUN
0808
6

Error correction

Cause
Line rises up completely or
partly over the upper edge of
label.
Line rises up completely or
partly over the bottom edge of
label.
One res. several characters of
the text is res. are not available
in the selected font.
Selected code is not available.
Selected position is not
available.
Selected font is not available.
Selected font is not available.
While measuring no label was
found.
Set label length is too large.
No label available.
Soiled label photocell.
Labels not inserted correctly.
During the print order the
ribbon roll becomes empty.
Defect at the transfer ribbon
photocell.
Stop bit error.
Parity error.
Loss of data at serial interface
(RS-232).
Service instructions
Error correction
Remedy
Move line down (increase Y
value).
Check rotation and font.
Move line up (reduce X value).
Check rotation and font.
Change text.
Change font.
Check code type.
Check position.
Check font.
Check font.
Check label length and if labels
are inserted correctly.
Restart measuring anew.
Insert new label roll.
Check if labels are inserted
correctly.
Clean the label photocell.
Change transfer ribbon.
Check transfer ribbon photocell
(service functions).
Check stop bits.
Check baud rate.
Check cable (printer and PC).
Check parity.
Check baud rate.
Check cable (printer and PC).
Check baud rate.
Check cable (printer and PC).
