Dynacode series
0808

11 Connection plan of interfaces

11.1 Centronics

Figure 58
PIN
1
2-9
10
11
12
13
14
15-16
18
19-30
31
32
33-35
36
11.2 RS-232
Figure 59
PIN Signal
1 XXX
2 RXD
3 TXD
4-5 GND
6-9 XXX
Service instructions
Connection plan of interfaces
Signal
STROBE
DATA1-8
ACK
BUSY
PERROR
SELECT
AUTOFD
GND
VCC1284 (4,7V)
GND
INIT
FAULT
XXX
SELECTIN
65
