Connection plan of back panel plugs
Illustration: connector -
soldering side
Connector socket
encoder
Electrical data of
encoder
Connection of
encoder
64
10.3 Touch Panel
Power supply for touch panel: 12-pole DIN bushing
Figure 55
PIN
A, B, C, D, E, L
F, G, H, J, K, M
10.4 Encoder (continuous mode)
5-pin connecting bushing, contacts according to DIN 45322
PIN1 = 5 VDC
PIN2 = Encoder signal (channel A)
PIN3 = Encoder signal (channel B)
PIN4 = GND
Figure 56
Operating voltage:
Output signal:
Resolution:
Figure 57
Service instructions
Signal
48V
GND
5 VDC
TTL level
Can be set at print module
Dynacode series
0808
