Connection plan of interfaces

66

11.3 Ethernet

Figure 60

PIN RJ45-

Bezeichnung

Buchse

1

2

3

4

n/c

5

n/c

6

7

n/c

8

n/c

11.4 USB 1.0

2

3

Figure 61

PIN

Signal

1

n/c

2

D−

3

D+

4

GND

Service instructions

TX+

TX−

RX+

RX−

1

4

Dynacode series

0808
