Dynacode series
Error message
95 Scanner layout
difference
96 COM break
97 COM general
98 No software
printhead FPGA
99 Load software
printhead FPGA
100 Upper position
101 Lower position
102 Vacuum plate empty
103 Start signal
104 No print data
105 Printhead
106 Invalid Tag type
107 RFID invalid
108 GS1-128 invalid
109 EPC parameter
0808
Cause
Scanner data does not
correspond to bar code data.
Serial interface error.
Serial interface error.
No printhead-FPGA data
available.
Error when programming
printhead-FPGA.
Sensor signal up is missing
(option APL 100).
Sensor signal down is missing
(option APL 100).
Sensor does not recognise a
label at vacuum plate
(option APL 100).
Print order is active but device
not ready to process it.
Print data outside the defined
label.
Selection of wrong module type
(design software).
No original printhead is used.
Wrong Tag type.
Tad data do not match the Tag
type in the printer.
RFID module is not activated.
No RFID data can be
processed.
Transferred GS1-128 bar code
is invalid.
Error at EPC calculation.
Service instructions
Error correction
Remedy
Check adjustment of scanner.
Check scanner settings /
connection.
Check settings for serial data
transmission as well as cable
(printer-PC).
Check settings for serial data
transmission as well as cable
(printer-PC).
Please contact your
responsible distributor.
Please contact your
responsible distributor.
Check input signals /
compressed-air supply.
Check input signals /
compressed-air supply.
Check input signals /
compressed-air supply.
Check start signal.
Check selected module type.
Check selection of left/right
version.
Check the used printhead.
Contact your distributor.
Adapt data or use the correct
Tag type.
Activate RFID module or
remove RFID data from label
data.
Verify bar code data (see GS1-
128 bar code specification).
Verify data (see EPC
specification).
39
