Installing The Intrusion Switch - Dell PowerEdge R530xd Owner's Manual

1. Ensure that you read the
2. Follow the procedure listed in
3. Remove the cooling shroud.
Steps
1. Disconnect the intrusion switch cable from the connector on the system board.
2. Slide the intrusion switch out of the intrusion switch slot.
Figure 14. Removing and installing the intrusion switch
1. intrusion switch
3. intrusion switch connector
Next steps
• Install the intrusion switch.
• Install the cooling shroud.
Related Tasks
Removing the cooling shroud

Installing the intrusion switch

Installing the cooling shroud
Installing the intrusion switch
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
1. Ensure that you read the
Safety instructions.
Before working inside your
Safety instructions.
system.
2. intrusion switch holder
51
