System battery

Replacing the system battery

Prerequisites
1. Ensure that you read the
2. Follow the procedure listed in
3. Remove the cooling shroud.
NOTE: If applicable, close the expansion card latch on the cooling shroud to release the full
length card.
4. If applicable, disconnect the power or data cables from expansion card (s).
5. If applicable, remove the expansion card riser
WARNING: There is a danger of a new battery exploding if it is incorrectly installed. Replace the
battery only with the same or equivalent type recommended by the manufacturer. For more
information, see the safety information that shipped with your system.
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
Steps
1. Locate the battery socket, see
CAUTION: To avoid damage to the battery connector, you must firmly support the connector
while installing or removing a battery.
2. To eject the battery, press firmly on the edge of the positive side of the battery in the direction of the
arrow as shown in the illustration below.
Safety instructions.
Before working inside your
System board connectors.
system.
121
