■ Sync Display Menu

If there are no items in the item list, the sync display menu is not shown.
・Select All
・Clear All
・Sync Display
・Sync Display Layout
Refer to page 3-25 for details.

■ Settings Menu

・Register Camera
・Camera Connection Settings Specify the parameters set to the cameras when starting camera
・Options
Caution
9 - 12
Specify all items in the item list for sync display.
Clear all items in the item list for sync display
Switch between sync display/selected item display.
Set the image layout during sync display.
Camera registration is required for fx and ULTRA Cam camera
connections. Refer to page 4-2 for details.
connections. Refer to page 6-2 for details.
Various HXLink settings. Refer to page 7-2 for details.
With the exception of some states, the option settings are enabled when
"OK" is clicked.
