■GUI Settings
Settings for the HXLink GUI.
・Selects the operational mode in the HXLink GUI.
Basic Mode
Expert Mode
The F12 key on the keyboard can be used to switch between the "Basic Mode" and the
"Expert Mode".
・Click RESET
settings toolbar display.
・Select from individual or batch conversion (list) in the dialogue displayed while downloading or
during format conversion.
Individual Conversion "Save As" dialogue for a single camera.
Batch Save／Batch Conversion (List)
・GUI Settings When 1 Camera is Connected
Click "Detailed Settings" in the control menu or "Detailed Settings" on the item toolbar or
camera parameters toolbar to select the window displayed.
Camera Details (Individual)
List of Camera Settings (List)
(00292)H
Performs basic operations.
Performs detailed operations.
on the initial settings on the toolbar to return to the initial
The range for downloading ・ format conversion is shown on the
slider bar.
Dialogue in list format to batch download or convert the format of
MCFF files.
With multi trigger recorded images, the range for downloading ・
format conversion is specified for each block.
Refer to page 8-14 for details.
Uses the "Camera Details" dialogue for one camera.
Uses the "List of Camera Settings" window in the list format.
7 - 3
