■ Auto White Balance Function

The auto white balance function calculates the appropriate RGB gain value from image
currently displayed.
Any of the following can be used to calculate the appropriate RGB gain value using the auto white
balance.
・Click "White Balance" -> "AUTO" -> " Change Settings" on the "Adjust Image Quality"
menu.
・ Select "White Balance" in the image quality adjustment section of the "Item Toolbar",
select AUTO, and then click
Click "AUTO" -> "Change Settings" in the "Adjust Image Quality" menu to display the following
confirmation dialogue.
Click "OK" to calculate the proper RGB gain value from the currently displayed image, which will
be reflected on the image.
If the auto white balance hasn't been set, click "White Balance" -> "AUTO" -> "Select AUTO"
on the "Adjust Image Quality" menu to calculate the proper RGB gain value from the auto
white balance value of the MCFF top frame and display on the image.
If the AUTO settings are changed, click "Select AUTO" to display the RGB gain image from the
previous "AUTO" selection.

■ Auto Conversion Settings

When opening a MCFF format or a CIF format, files can be opened to reference the file
conversion settings (FCV) for the image quality adjustment, conversion settings and specified
range settings and the image is displayed with the details in the conversion setting file.
Click "Options" on the "Setting" menu to specify the automatic conversion settings ON/OFF
under the auto conversion settings tab in the "Options" dialogue. Automatic conversion settings
can be specified even when "Options" is clicked in the image quality adjustment section of the
"Item Toolbar". Refer to page 7-20 for details.

■ File Conversion Settings (FCV File)

Save the settings for image quality adjustment and conversion settings for saving the converted
range in "File Conversion Settings (FCV)" and these settings can be reused.
Load the FCV file and the item settings in the file can be employed.
Items not requiring setting should be disabled or deleted.
Refer to Appendix B for FCV details.
The FCV files may be changed without prior notice.
5 - 20
"Start White Balance".
