■ Superimpose Information
Specify the information to be superimposed in "Conversion Settings".
Superimposed
Items related to "Superimpose Information" on the "Conversion Settings" menu
Select superimpose information
Show Frame
Show Comments
Comment Position
Show IRIG Lock, Event 2
Font Size of Superimposed Information
5 - 22
Select information to be superimposed on the converted image.
(None, Frame, All, Custom)
If "All" is selected, the "ID", "Scene", "Trigger Timing", "Trigger
Time", "Frame Number",
identification number), "Frame Rate", "Shutter Speed", "Event
Frame" and "Camera Type" are superimposed on the image.
If "CUSTOM" is selected, the items to be superimposed can be
individually specified.
Select the format for the frame number.
(Frame, Relative Time (sec), Relative Time (msec), Absolute
Time)
Select the recording comments to be superimposed on the
converted image.
Select the position where the recording comments are
superimposed. (Top left, bottom left, top right, bottom right)
Check it to superimpose "IRIG lock status" and "EST2
signal ON/OFF status" for the current frame.
information applied to the image.
Small
Medium
Large
Extra Large
Superimposed
information
"Nickname",
IRIG signal locked (green)
IRIG signal not locked or M-HUB in use
(red)
EST2 signal ON
Select the font size for the superimposed
For image sizes of 512x512 and 640x480.
For image sizes of 768x592
For image sizes of 1280x1024
For image sizes of 2560x1920
"CID" (camera
