■AOI(Brightness Detection Area, Area Of Interest)

With AE control or image trigger, the subject range (AOI) must be specified. To specify the AOI,
use any of the following.
・
Select the camera in the "Item List" and select "AOI" from the "Control" menu.
・
Select "AOI" from the "Control" window.
・
Select "AOI" from the "Camera Details" dialogue.
・Select "AOI" from the "Recording Parameters" in the "List of Camera Settings".
Select any of the following for AOI.
FULL
CENTER
UPPER
LOWER
LEFT
RIGHT
CUSTOM
4 - 46
The entire frame is the range.
50% of a rectangle (area of 25%) from the center of the frame is the
range.
The upper half of the frame is the range.
The lower half of the frame is the range.
The left half of the frame is the range.
The right half of the frame is the range.
The rectangle specified is the range.
