Color, Build, Print File And Help - 3D Systems CubePro 3D Printer User Manual

Movement
Geometry Value
Fields
Move X Button
Move Y Button
Auto Place
Move Model
Scale Value Field
- to mm
+ to Inch

Color, Build, Print File And Help

Material 1 ColorSelect shells to be rendered by print jet 1
Material 2 ColorSelect shells to be rendered by print jet 2
Material 3 ColorSelect shells to be rendered by print jet 3
Build Button Process the 3D model to obtain a print file
Open Open a print file
Enter the appropriate values to move the model.
Once a value has been entered, select the button to
move the model left or right.
Once a value has been entered, select the button to
move the model forward or backward.
Auto Place the model to the center of the print area.
Once this button has been selected, left click on the
model and drag it into position.
Enter the scale percentage
Scale the 3D model to the millimeter value entered
in the field.
Scale the 3D model to the inch value entered in the
field.
Scale
Revert
Rotate
Geometry
Value fields
X
Y
Z
Revert
Close Close a print file
Save Print File Save a build print file
Send a print job through the wireless network to a
Send
connected printer
Help Help menu
Scale the model by the specified
percentage.
Undo the scaling and revert back to the
original size.
Enter values to rotate the model
Rotate the model front-to-back on the X axis
by the specified value.
Rotate the model left and right on the Y axis
by the specified value.
Rotate the model up and down on the Z axis
by the specified value.
Undo the applied rotation and revert to the
original position.
