3D SYSTEMS- Procedures
PROJET® 3500 PRINTERS
"Procedure: VisiJet® M3 Black Material Hygiene"
Revision date: August 29, 2014
1
1
2014
9
8

Advertisement

loading
Need help?

Need help?

Do you have a question about the PROJET 3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for 3D Systems PROJET 3500

  • Page 1 3D SYSTEMS- Procedures PROJET® 3500 PRINTERS “Procedure: VisiJet® M3 Black Material Hygiene” Revision date: August 29, 2014 2014 年 月 日...
  • Page 2 Objectives After completing this procedure you will be able to: Perform VisiJet® M3 Black/printhead hygiene maintenance procedure.
  • Page 3 VisiJet® M3 Black Printhead Hygiene • It strongly recommended to run this printhead hygiene procedure after EVERY build to ensure optimal, long life performance of the printhead when running with VisiJet® M3 Black.
  • Page 4 VisiJet® M3 Black Printhead Hygiene Criteria for Printhead Hygiene: Perform this procedure after EVERY BUILD. PROCEDURE: STEP 1: From the ProJet® Operator Panel: Select the Tools icon.
  • Page 5 VisiJet® M3 Black Printhead Hygiene STEP 2: In the next screen select Print Diagnostics. STEP 3: In the next screen select Test Print.
  • Page 6 VisiJet® M3 Black Printhead Hygiene The printer will start a print that will be approximately 10 minutes in duration. The build will lay down 1 layer of part and support material. STEP 4: Inspect the test build for consistency A good test build should be •...
  • Page 7 STEP 6: If after three (3) Test Print attempts, the build does not pass: Example of a Bad Test Print Contact your 3D Systems Service • Notice the blank areas. This represents jets • Personnel who will provide you with that are partially or fully clogged or missing.
