TMS320C6670
Multicore Fixed and Floating-Point System-on-Chip
SPRS689D—March 2012
Table 7-71 HyperLink Peripheral Switching Characteristics (Part 2 of 2)
(see Figure 7-40, Figure 7-41 and
No.
4 tosu(MCMTXPMDAT-MCMTXPMCLKL) Setup time - MCMTXPMDAT valid before MCMTXPMCLK low
5 toh(MCMTXPMCLKL-MCMTXPMDAT)
End of Table 7-71
Figure 7-40 HyperLink Station Management Clock Timing
Figure 7-41 HyperLink Station Management Transmit Timing
<xx> represents the interface that is being used: PM or FL
Figure 7-42 HyperLink Station Management Receive Timing
<xx> represents the interface that is being used: PM or FL
204 TMS320C6670 Peripheral Information and Electrical Specifications
Figure 7-42)
Parameter
Hold time - MCMTXPMDAT valid after MCMTXPMCLK low
MCMTX<xx>CLK
MCMTX<xx>DAT
MCMRX<xx>CLK
MCMRX<xx>DAT
1
2 3
4 5 4 5
6 7 6 7
Copyright 2012 Texas Instruments Incorporated
www.ti.com
Min Max Unit
0.25*C2-0.4 ns
0.25*C2-0.4 ns
