Data content description (Continued)
D Selcall setting
Command: 1A 42
q w
X X X X X X X X
Call type Call ID
data or Link ID
Call type data
q
Call type q Data
Selective
Phone
Message
Send Position
Get Position
Get Status
Emergency
Channel Test
Stun
Call ID, Link ID
w
If the ID is less than 6 digits, enter F into the rest
digits.
Example: Call ID is 123, enter 123FFF.
Telephone number, Message, PIN code
r
• Telephone number: 1 to 16 digit(s)
• Message: 1 to 64* characters
ASCII code (20 to 7Eh)
* Icom Selcall: Up to 64 characters
Open Selcall: Up to 32 characters
(After 33 characters are omitted.)
• PIN code*: 1 to 10 digit(s)
ASCII code (30 to 39h Number)
* Open Selcall only
D Priority Network setting
Command: 1A 50
X X X ...... X X
X
Network name
w
ASCII 1 to 20 characters
V4.01–
e r
......
X X
F F F F
Resevation Telephone number
Message, PIN code
Telephone number/
Message/PIN code
00 —
01 Telephone number
02 Message
03 —
04 —
05 —
21 —
24 —
28 PIN code
ASCII code (30 to 39h
Number)
w: Network name
q: Priority data
00 ： OFF
01 ： ON
D Position data
Command: 1A 60
X X
......
X X
Latitude
q
ASCII 11 Bytes.
Longitude
e
ASCII 12 Bytes.
D Model information
Command: 1A A3
q: Model name (ESN)
......
X X
......
X X
y: Main CPU version
ESN: Electronic Serial Number
Hardware type
r
Hardware type
EXP
AUS
UN
NoOP
7
q: Latitude
......
X X X X X X
w: Separator (0×2C)
w: Version (ESN)
e: Serial number (ESN)
......
X X X X X X X X
r: Hardware type
t: Hardware version
......
X X X X X X X
u: Front CPU version
r Data
0 (ASCII)
1 (ASCII)
2 (ASCII)
3 (ASCII)
e: Longitude
X X
X X X X X X
......
X X X
i: DSP version
