This information is discribed using Version 4.01 or later firmware. Earlier versions are some different.
CI-V connection
The transceiver can be connected to a PC with a USB
cable. The Icom Communications Interface-V (CI-V)
controls the transceiver.
• A USB cable (A-B type, user supplied)
The required USB driver and driver install guide can be
downloaded from the Icom web site.
GO to "http://www.icom.co.jp/world," then click "Support,"
"Firmware Updates / Software downloads" in sequence.
* The download procedure on the web page may
change without notice.
Data format
The CI-V system can be operated using the following
data formats. Data formats differ, depending on
command numbers. A data area or sub command is
added for some commands.
Controller to IC-F8101
q w
FE FE 8A
FE FE E0
q w
IC-F8101 to controller
V4.01–
iF8101
CI-V information— Ver. 4.01 or later
e r t
E0 Cn Sc Data area
8A Cn Sc Data area
e r t
y u
FD
FD
y u
1
OK message to controller
FE FE E0
FE FE E0
NG message to controller
8A FB FD
8A FA FD
A-7264-2EX
