  • Page 1 INTELLIGENT DISPLAYS 6500 ARCO EALITY R9001960 R9001969 ’ WNER ANUAL 30012001 R5976182/01 Downloaded From projector-manual.com Barco Manuals...
  • Page 2 Barco nv Media Noordlaan 5, 8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: media@barco.com Visit us at the web: www.barco.com Printed in Belgium Downloaded From projector-manual.com Barco Manuals...
  • Page 3 Changes Barco provides this manual “as is” without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
  • Page 4 Downloaded From projector-manual.com Barco Manuals...

  • Page 5: Table Of Contents

    7.2.5 Edit file ......................... . . 44 R5976182 BARCOREALITY 6500 30012001...
  • Page 6 9.6.2 Projector Address ....................... . 80 R5976182 BARCOREALITY 6500 30012001...
  • Page 7 B. BARCO Control Manager................
  • Page 8 Table of contents R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 9: Packaging And Dimensions

    Save the original shipping carton and packing material, they will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 10: Lens Packaging

    Lenses are supplied as an individual item. They are packed in a carton box. 1.4 Dimensions Dimensions overview Dimensions are given in mm (1 inch = 25.4 mm) Image 1-2 Front view dimensions projector R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 11: Side View Dimensions Projector

    1. Packaging and Dimensions Image 1-3 Side view dimensions projector Image 1-4 Top view dimensions projector R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 12 1. Packaging and Dimensions R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 13: Installation Guidelines

    The use of recessed ceiling lights and a method of dimming those lights to an acceptable level is also important. Too much ambient light will ‘wash out’ of the projected image. This appears as less contrast between the darkest R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 14: Configuration

    The projector can be installed to project images in four different configurations : • Front/table • Rear/table • Front/ceiling • Rear/ceiling Positioning the projector Drawings are given for a nominal lens position. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 15: Lenses

    SH Screen height (image height) PD Projector distance, distance between screen and projector 2.3 Lenses Overview • Lenses • Lens selection • Lens formulas • Lens installation • Cleaning the lens R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 16: Lenses

    2. Installation Guidelines 2.3.1 Lenses Available lenses The following lenses are available, or will become available (contact a BARCO service center) as an option : Lenses Standard version QFD(1.27:1) R9840400 QFD(2.5:1) R9840290 QFD(1.4-2.1:1) R9840380 QFD(2.1-3.0:1) R9840390 QFD(3.5-4.5:1) R9840060 R9840100 QFD(4.5-6.0:1)

  • Page 17: Lens Installation

    FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air. DO NOT use any liquid to clean the lenses. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 18: Batteries

    5. Repeat for the second battery. 6. Insert the batteries as indicated in the RCU (battery type AA or LR6 or equivalent). 7. Put the battery cover on its place. (image 2-6, image 2-7) R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 19 The common address can be zero (0) or one (1). The standard RCU are setup for common address zero. To change the common address of the RCU, contact a BARCO service center. If it is necessary to program the projector address into the RCU, see chapter ’Getting Started’.
  • Page 20 2. Installation Guidelines R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 21: Connections

    Starting image projection. 1. Press Stand by key once on the local keypad or on the remote control. The projector mode indication lamp will be green (image 4-2, image 4-3) Image 3-1 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 22 The total lifetime of the lamp for a safe operation is 1000 hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Using a lamp for more than 1000 hours is dangerous as the lamp could explode.

  • Page 23: Switching To Standby

    If only one source is found, this source will be projected. If different sources are found, the priority is as follow Video S-Video 5 cable input Computer input SDI and IEEE input are never automatically selected. When a RCVDS is connected to the projector, the ’Automatic’ selection is disabled. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 24: Inputs Via Rcvds05

    Which signals can be connected to the 5 cable input. The following signals can be connected to these BNC connectors : Connector name RGBHV RGBS RGsB Composite video Video Super Video R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 25 All sources of the RCVDS can now be accepted by the projector. Audio Connection Connect the audio input to one of the 3 audio inputs. See Video - audio lock, page 57 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 26: Computer Input/Monitor Output

    Composite Video is a single video signal that contains luminance, color and synchronization information. NTSC, PAL and SECAM are examples of composite video systems. What can be connected to the Video input? Composite video signals from a VCR, OFF air signal decoder, etc... No loop through. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 27: S-Video Input

    An active loop through of the SDI input signal is provided for monitoring or for double or triple stacking applications. An active loop through of the SDI input signal is provided for monitoring or for double or triple stacking applications. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 28: Ieee 1394 Input

    1394 setup command in the Random access adjustment mode can be used to start the decoding manually (only for sources that not fully implement the AV/C protocol). 3.6 Communication connections Overview • RS232 • Communication with peripherals • Mouse • Network Connection R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 29: Rs232

    For more information about the use of the RCVDS05, consult the owner’s manual of the RCVDS05. 3.6.3 Mouse When available ? Mouse function is only available with the Executive Remote Control (Order number : R9829960). The computer can then be con- trolled via the projector. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 30: Network Connection

    8. Press ENTER to toggle between [A], [B] or [C]. 9. Press several times EXIT or ADJUST to return to the operational mode. See also Video - audio lock, page 57in chapter Random Access adjustment mode. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 31: Getting Started

    "pause" (blanked picture, full power for immediate restarting) • direct access to all connected sources. 4.2 Terminology overview Overview The following table gives an overview of the different functionalities of the keys. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 32: Rcu Function Indication

    Picture controls press to adjust the projected image. Phase press to adjust the phase of the projected image. FREEZ press to freeze the projected image. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 33: Operating The Projector

    Starting image projection. 1. Press Stand by key once on the local keypad or on the remote control. The projector mode indication lamp will be green (image 4-2, image 4-3) Image 4-2 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 34 The total lifetime of the lamp for a safe operation is 1000 hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Using a lamp for more than 1000 hours is dangerous as the lamp could explode.

  • Page 35: Switching To Standby

    What can be done ? For quick change of the the on-screen color of the highlighted items. The highlighted items on the menus can be displayed in red, green or yellow. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 36: Using The Rcu

    Pointing to the reflective screen 1. Point the front of the RCU to the reflective screen surface. (image 4-6) Image 4-6 Pointing the RCU via the screen to the Ir sensor R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 37: Wired Rcu Connection To The Projector

    IR sensor. Image 4-8 RCU directly to the IR sensor R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 38: Projector Address

    If the address is not entered within 5 seconds, the RCU returns to its default address (zero address) and control all projectors in the room. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 39: Controlling The Projector

    Use the - button for a lower volume. Bass Bass control adjusts the bass level (low tones). Use the + button for more low tones. Use the - button for less low tones. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 40: The Pause Key

    The sound is not interrupted. The display on front of the projector will show a "P". To restart the image : • Press Pause key. • Press EXIT key • Select a source number. The Selection key See Quick lens Adjustment, page 31 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 41: Start Up Mode

    START UP MODE NETWORK CONFIGURATION more ... Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 5-3 Menu 5-4 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 42 5. Start Up mode R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 43: Auto Image Adjustment

    The menu is automatically exited. The adjustment values will be saved when switching to another source. AUTO IMAGE ADJUST ACTION : FULL AUTOMATIC Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 6-3 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 44: Action

    2. Press ENTER to toggle between Full automatic, New File or Manual. Note: The values of automatically adjusted sources will not be saved. AUTO IMAGE ADJUST ACTION : FULL AUTOMATIC Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 6-4 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 45: Random Access

    7. Random Access 7. RANDOM ACCESS 7.1 overview flow Overview Image 7-1 Random Access Adjustment overview flowchart R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 46: Picture Services

    (see File options, page 50, in this chapter). Files with a ~ in front of the file name are temporary files. These files will be deleted when switching to another source. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 47: Start Up Of File Services

    Active file : Video525.c50 Select with ↑ or ↓ Select with ↑ or ↓ , → then <ENTER> <ENTER> to accept <EXIT> to return. <EXIT> to return. Menu 7-3 Menu 7-4 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 48: Edit File

    The Edit file menu makes it possible to change the settings of the file according to the real settings of the connected source. Consult the source specification before entering the data. • Start up • Changing the settings • Correct value R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 49: Start Up

    During the installation of a file with LOAD, the horizontal period, the total number of vertical lines and the interlaced mode are automatically measured and filled in in the menu table. These values will be available when starting up the EDIT procedure of an active file. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 50 0 and 255. Change the value by pushing the cursor key ↑ or ↓. Clamp width The width of the clamp pulse can be any value between 0 and 255. Change the value by pushing the cursor key ↑ or ↓. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 51: Example For Clamp Position [Trailing]

    [leading]. Toggling to [trailing] is only necessary for special applications where the trailing edge of the sync signal has to be taken as a reference. Use the ENTER key to toggle between [leading] or [trailing] R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 52: Rename

    Frome file name : Video525.s01 To file name : demo.c10 Select with ← or → Preprogram with ↑ or ↓ or numeric keys <ENTER> to confirm <EXIT> to return. Menu 7-14 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 53: Copy

    Frome file name : Video525.s01 To file name : demo.c10 Select with ← or → Preprogram with ↑ or ↓ or numeric keys <ENTER> to confirm <EXIT> to return. Menu 7-17 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 54: Delete

    The following items will be discussed within Picture Tuning : • Start up • • Color Temperature • Gamma • Decoding • Dynamic Color Depth • Noise Reduction • Input Balance R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 55: Start Up

    This CTI function applies to PAL and NTSC video or S-video inputs only. 7.3.3 Color Temperature Available Color temperatures • Projector white • Broadcast 3200K • Film 5400K • Video 6500K • Computer 9300K • Custom balance R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 56: Gamma

    COLOR TEMPERATURE GAMMA DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 7-28 7.3.5 Decoding Decoding is only for NTSC signals. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 57: Dynamic Color Depth

    NOISE REDUCTION INPUT BALANCE Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 7-30 7.3.7 Noise Reduction Purpose Reduces noise and pixel jitter in all video and data sources R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 58: Input Balance

    DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 7-32 Menu 7-33 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 59: Audio Tuning

    When a sound control is selected by highlighting the item with the cursor key, a text box with a bar scale, icon and function name of the control, e.g. ’Volume’ appears on the screen (only when text is ON). The length of the bar scale indicates the current memory setting for this source. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 60: Mute

    Fade on 15 : no sound reproduction on the internal loudspeakers but max on the external loudspeakers with the same volume level as adjusted with the volume control. 7.4.5 Mode Purpose To switch the sound reproduction between mono and stereo. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 61: Video - Audio Lock

    Entering the value with the digit keys. Therefore, press ENTER to select the indicated value and enter the desired value with the digit keys. Press ENTER to confirm the entered value. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 62: Geometry Start Up

    When adjusting the horizontal size, the left side of the image is fixed and only the right side can be moved to its exact position. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 63: Side Keystone

    (or noise). A ’0’ on the bar scale indicates no blanking. Which blanking adjustments are available ? • top blanking • bottom blanking • left blanking • right blanking R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 64: Aspect Ratio

    Within the Geometry options menu, it is possible to set up the side keystone for the active file only or for all files equal. [No] = keystone has to be adjusted file per file. [Yes] = keystone correction the same for all installed files. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 65: Ieee 1394

    Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 7-52 Menu 7-53 7.6.2 IEEE 1394 Control Overview • Start up • IEEE 1394 Setup • Audiodecoding R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 66: Start Up

    1. Push the cursor key ↑ or ↓ to highlight Audiodecoding. (menu 7-57) 2. Press ENTER to toggle audiodecoding between [on] or [off]. IEEE 1394 CONTROL 1394 SETUP AUDIODECODING : [ON] Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 7-57 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 67: Camcorder Control

    PAUSE PLAY FAST REVERSE REWIND PLAY SLOW REVERSE FAST FORWARD Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 7-58 Menu 7-59 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 68 7. Random Access R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 69: Installation Mode

    <EXIT> to return. Menu 8-1 Menu 8-2 Menu 8-3 8.3 Input slots What can be done ? The input configuration of the variable inputs is shown in the Input slots menu. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 70: No Signal

    What will happen ? If there is no signal connected to the projector, • The background color can be black or blue • The projector can shutdown after a certain time. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 71: Changing The Background Color

    <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 8-8 Menu 8-9 8.4.3 Changing the Shutdown time Range The shutdown time can be set between 5 min. and 60 min. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 72: Lens Adjustment

    INSTALLATION INPUT SLOTS NO SIGNAL LENS TEXT BOX POSITION QUICK ACCESS KEYS START UP MODE NETWORK CONFIGURATION more ... Select with ↑ or ↓ then <ENTER> <EXIT> to return. Menu 8-12 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 73: Text Box Position

    START UP MODE NETWORK CONFIGURATION more ... Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 8-14 Menu 8-15 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 74: Quick Access Keys

    During start up, the projector can show first the identification screen or a blank screen. The projector can start up with auto power. The projector starts up in the same power condition as it was before power supply was interrupted. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 75: Start Up With Identification Screen

    8.9 Network Configuration What can be done? The necessary network addresses (configuration) can be entered so that the projector can be connected to a LAN (local area ne DHCP Dynamic host configuration protocol R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 76: Peripheral

    When a RCVDS05 is connected to the projector, the type of output module of this RCVDS05 has to be defined in the 800 peripheral menu. • standard output module • 5 cable output module R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 77: Defining The Infrared Communication Protocol

    What can be done? The way of physical installation of the projector can be defined to the projector. The following installation configurations are possible: • front/table • front/ceiling • rear/table • rear/table R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 78: Osd Color

    <EXIT> to return. Menu 8-31 Menu 8-32 8.13 Internal Patterns What can be done with these internal patterns? The projector is equipped with different internal patterns which can be used for measurment purposes. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 79: Switching Mode

    SWITCHING MODE : [BLANKING] SHUTTER more ... Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 8-35 Menu 8-36 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 80: Shutter

    SWITCHING MODE : [BLANKING] SHUTTER more ... Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 8-37 Menu 8-38 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 81: Service Mode

    Projector Run Time: gives the total run time since the first start up. All projectors leave the factory with a run time of approxi- mately 24 hours. • Projector Serial number: indicates the fabrication number of the projector. This number can be useful when calling for technical assistance. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 82: Change Password

    How to enable or disable the password function ? This item is password protected when the password strap is installed. The password function is enabled when the password strap on the controller module is installed. Consult an authorised Barco service technician to change the strap position.

  • Page 83: Change Language

    RESET LAMP RUNTIME LAMP RUNTIME HISTORY LAMP DIMMING MORE... Select with ↑ or ↓ Select with ↑ or ↓ then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Menu 9-10 Menu 9-11 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 84: Projector Address

    1. Enter with the digit keys on the RCU or the local keypad Or , pushing the cursor key ↑ or ↓ until the new value is reached. Only addresses between 0 and 1 are valid. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 85: Change Baudrate Pc

    <ENTER> to accept <EXIT> to return. <EXIT> to return Menu 9-16 Menu 9-17 9.9 Lamp Run time History What can be done? Getting an overview of the different lamp run times R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 86: Lamp Dimming

    A projector starts always with full lamp power. 9.11 BARCO Logo What can be done? The BARCO logo can be added to the image, in overlay or on a background, on any place on the screen. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 87: Panel Adjustments

    OFF: no key on the RCU is used to display the BARCO logo. TEXT: the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational mode).

  • Page 88: Uniformity

    <EXIT> to return. <EXIT> to return. Menu 9-27 Menu 9-28 9.15 I2C Diagnoses What can be done? This menu gives an overview of the correct working of the I²C controlled IC’s. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 89 C0H ### LCD DRIVER C4H ### LCD DRIVER C8H ### LCD DRIVER CCH ### Select with ↑ or ↓ then <ENTER> <EXIT> to return. <EXIT> to return Menu 9-29 Menu 9-30 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 90 9. Service mode R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 91: Standard Source Set Up Files

    6. Ftot : total pixels on one horizontal line. 7. Pact: active pixels on one horizontal line. 8. Ltot: total lines in one field 9. Lact: active lines in one field. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 92 48,287 64,125 1328 1024 SUNXGA70 1024x768 70,041 56,596 74,250 1312 1024 SUNXGA77 1024x768 77,069 62,040 84,375 1360 1024 SUP_MAC 1024x768 60,000 48,780 63,999 1312 1024 SVGA_56V 800x600 56,250 35,156 36,000 1024 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 93 1024 XGA_75 1024x768 75,781 61,080 86,000 1408 1024 XGA75_GS 1024x768 74,534 59,701 79,284 1328 1024 XGA_85 1024x768 85,000 68,680 94,500 1376 1024 XGA_100 1024x768 100,000 80,800 100,000 1368 1024 Table A-1 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 94 A. Standard Source Set Up Files R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 95: Barco Control Manager

    The Barco Control Manager has been successfully tested on Microsoft Windows platform (98/NT 4.0/Windows 2000) with Internet Explorer 4.0 or higher and Netscape 4.7 or higher. On other platforms and with other browsers, it should run fine when the browser supports Java Applets and supports the Java Swing library.

  • Page 96: Control Manager Start Page

    Information on the Start Up page. The nick name of the projector is shown in the middle of the screen. E.g. default indicated as ’Barco - projector’. Below the location of the projector, default indicated as ’Location’. This name and location can be replaced by any other name or location, see Config- uration window / SettingsSettings, page 106.

  • Page 97: Control

    To select an item, click on it in the menu bar and select the desired item in the drop down menu. B.4 Control Overview • Start up • General Control • Source • Image Settings • Image Enhancement • Lens adjustment • Geometry adjustment • Blanking adjustment • Audio Adjustment R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 98: Start Up

    Image settings Contrast Brightness Color Tint Sharpness Phase Gamma Image enhancement Noise reduction Dynamic Color Dept CTI on/off Decoding ’ebu’ or ’ire’ Lens Zoom Focus Shift Geometry Image Shift R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 99: General Control

    (off is equal to standby) • pauze on/off • freeze on/off • test on/off The 800 peripheral present item is not selectable, but if such a peripheral is present the green light lights up. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 100: Source

    The source names next to the slot indications can be freely chosen. To enter or to change these names, go to ’Configuration’ and select item ’Source’Source, page 107. (image B-7) Image B-7 Source selection R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 101: Image Settings

    Changing a setting will have inmediate influence on the displayed image. Image B-8 While changing one off these image settings with the RCU, the values indicated on the image settings web page will only be changed after 15 min. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 102: Image Enhancement

    While changing one off these enhanced image settings with the RCU, the values indicated on the enhanced image settings web page will only be changed after 15 min. B.4.6 Lens adjustment How to change The lens adjustment can be done with lens web page . R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 103: Geometry Adjustment

    ( - 5 mm to + 5 mm) B.4.7 Geometry adjustment What can be adjusted Shift, Size and Keystone can be adjusted. Image B-11 Geometry adjustment R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 104: Blanking Adjustment

    (or noise). The blanking values are given in a text box below the image. A ’0’ value in the text box indicates no blanking. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 105: Blanking Adjustment

    1. Click on a side of the image and drag up/down or left/right until the desired blanking is reached (steps of 8 pixels). Or , Click on the arrows of the chosen side until the desired blanking is obtained (every click is one pixel). To return to the default position, click on Reset. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 106: Audio Adjustment

    While changing one off these audio settings with the RCU, the values indicated on the audio settings web page will only be changed after 15 min. B.5 Configuration Overview • Start up • Mail Set up • Security • Data & Time • Settings • Source R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 107: Start Up

    3 mail addresses can be configured to send feedback about the status of the projector at different time intervals . The content of the mail can be selected during configuration of the mail setup. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 108: Security

    Repeat the above steps for the other mail configurations if necessary. B.5.3 Security What can be done The administrator can add or change the advanced user password and the administrator password. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 109: Data & Time

    B.5.4 Data & Time Internet Protocol. The network layer of TCP/IP. Required for communication with the internet. TCP/IP Transmission Control Protocol/Internet Protocol. The native protocol of the internet. Network time protocol R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 110: Settings

    Each time the projector is powered down, the date & time settings has to be filled out again when chosen for the second methode. B.5.5 Settings What can be done The projector nick name, location and SMTP server address can be filled in. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 111: Source

    2. Fill out the IP address for the SMTP server (e-mail server). B.5.6 Source What can be done The source screen allows to enter a name or nick name for each slot. These names will be visible on the Control Source screen. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 112: Diagnostics

    4. When finished, click on ’Apply’ to activate these names. These names will become visible when selecting Control item Source. B.6 Diagnostics Overview • Start Up • General Status • Job Log • Advanced Diagnostics R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 113: Start Up

    • run time • lamp life time • software version B.6.3 Job Log Overview The job log screen gives an overview of the last 30 logs stored in the projector. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 114: Advanced Diagnostics

    When a warning or error occured, one of the lights in the buttons will be red and the error list for that button will be expand on the right side of the advanced diagnostic screen. The occured error should be indicated by a red light. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 115: Source Numbers 81 - 86 And 91 - 96

    800 peripheral and 91 - 99 is shown in the diagram below. source input 1 source input 1 file A source input 91 file A’ source input 2 source input 2 file B source input 92 file B’ R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 116: Source Numbers 81 - 86

    82 source of slot 3 source number 83 source of slot 4 source number 84 source of slot 5 source number 85 source of slot 6 source number 86 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 117: Cleaning The Dustfilter

    3. Clean the dust filter with a dry cloth. 4. Re-insert the dust filter. 5. Secure their position by insertion and tightening 2 fixation screws. Image D-1 Opening the first dustfilter Image D-2 Second dustfilter R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 118 D. Cleaning the Dustfilter R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 119: Glossary

    WWW servers. Video Composite Video is a single video signal that contains luminance, color and synchronization information. NTSC, PAL and SECAM are examples of composite video systems. R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 120 Glossary R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 121: Index

    Values Color Temperature File options Available Temparatures Load common address Manipulations Configuration 10, 71 Rename Network Start up Projector Fuses Connection 22–26 Audio Communication Communication port Gamma input geometry R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 122 Quick Access Keys Projector 5–6, 9, 17, 19, 29, 31, 34–35 Definition Address Overview Controlling Programming Controlling Start up dimensions Start up mode 37, 70–71 Input facilities Auto power up 37, 71 R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 123 Picture Tuning Start up 14, 27, 32 Battery Temperature Terminology Ambiant Overview Treble Use of RS232 uniformity service mode 77–84 Barco logo baudrate PC change Video/audio lock build-up Volume R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 124 Index R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...
  • Page 125 Overview of possible adjustments ................. . . 95 R5976182 BARCOREALITY 6500 30012001...
  • Page 126 List of tables R5976182 BARCOREALITY 6500 30012001 Downloaded From projector-manual.com Barco Manuals...

  • Page 127: List Of Tables

    Second dustfilter.....................113 R5976182 BARCOREALITY 6500 30012001...

Table of Contents
