Removal Procedure

8.10 Removal of Humidifying Unit Gear

Warning
Step
1. Removal of the
humidifying Unit
Lift up the humidifying
1
unit gear to remove.
Disconnect the
2
connector [S116].
Remove the 2 screws
3
and remove the
humidifying rotor.
2. Removal of the safety
switch
1 Remove the safety
switch.
92
Be sure to wait 10 minutes or more after turning off all power supplies before
disassembling work.
Procedure
Motor for the humidifying rotor
Power cord
Black (sleeve color : blue)
2 2
Safety switch
4
4
Black (sleeve color : yellow)
Humidifying
unit gear
White (top)
Green (middle)
Black (bottom)
(R9845)
[S116]
(R9846)
Safety switch wire
harness (black)
Switch cover
(R9847)
Brown (sleeve color : blue)
Power
cord
1
Blue (sleeve
color : white)
3
(R9848)
SiBE81-909
Points
Humidifying Air Purifier
