SiBE81-909
Operating panel
Front indicator
lamps
Air inlet
Rear
Humidifying Air Purifier
Handle
Streamer pocket
Air inlet
Power supply
cord hook
Winds the cord for storing
unit.
Power supply cord
Side panel
Pocket lock
Prevents streamer pocket from opening inadvertently.
Use a coin to open.
Unlock
Coin
Lock
Pocket lock
Recyclable deodorizing cartridge
Streamer pocket
Waterwheel

Humidifying tray

Operation Manual
How to use the pocket lock
Unlock
Lock
To lock, turn to where the
meet.
Use to regenerate the recyclable
deodorizing cartridge.
Inserting into the streamer pocket
decomposes absorbed odors and
enables reuse.
Page 23, 24.

Humidifying filter

8
17
