- Page 1 SiBE81-909 Preliminary Humidifying Air Purifier...
-
Page 2: Table Of Contents
SiBE81-909 Air Purifier MCK75JVM-K 1.Introduction ......................2 2.Precautions for Use..................5 2.1 Required Conditions ................5 2.2 Applicable Room Area .................5 3.Functions ......................6 4.Specifications ....................7 4.1 Specifications ..................7 4.2 Dimension ....................9 4.3 Wiring Diagram ..................10 4.4 Packaging Drawing ................11 5.Operation Manual...................12 5.1 Safety Precautions ................12 5.2 Names and Operation of Each Part ...........16... -
Page 3: Introduction
Introduction SiBE81-909 1. Introduction “Clean Humidification”and “High Airflow Rate Purifying”are realized. Both “full humidification”and “full dust collection”can be used. Full Humidification Full Dust Collection 3 features for “Clean High airflow rate suction dust collection: 7.5m /min Humidification” Antibacterial humidifying filter... - Page 4 SiBE81-909 Introduction Full humidification New Design: High hydrostatic thin-type powerful fan Airflow “Double Path Mixing Structure” Humidified air temperature increases 2˚C Newly designed thin-type fan Dry air (Compared with Vaporized air and non-vaporized air a model without double path are mixed and discharged by shifting mixing structure) the humidifying filter from the fan.
- Page 5 Formaldehyde Removal Performance approved by academy (Corresponding ventilation) ventilation specified in the building standard law is Streamer discharge is a prominent Daikin technology, which shows more than 1,000 times carried out. decomposing force for the general glow discharge, and gets [A prize of the Institute of Electrostatics Japan].
-
Page 6: Precautions For Use
SiBE81-909 Precautions for Use 2. Precautions for Use Required Conditions Power Supply 1φ, 220-240/220-230V, 50/60Hz Miscellaneous • This product is for home use. Do not use for special purpose. • This product is for indoor use only. Do not use in bathroom or outdoors as it is not water/condensation proof. -
Page 7: Functions
Precautions for Use SiBE81-909 3. Functions Category Functions Structure Odor sensor Dust sensor Humidity sensor Temperature sensor Health & Clean Flash streamer discharge Catechin pre-filter Titanium apatite photocatalytic filter Bio-antibody filter – Attached pleated filter (sheets) Humidifying filter Deodorizing catalyst... -
Page 8: Specifications
SiBE81-909 Specifications 4. Specifications Specifications MCK75JVM-K Model Air purifying operation Humidifying operation Type Humidifying air purifier Color Black φ, Power supply 220-240/220-230V, 50/60Hz Running current 0.71 / 0.31 / 0.19 / 0.12 / 0.09 0.72 / 0.32 / 0.19 / 0.13 / 0.11... - Page 9 Specifications SiBE81-909 NOTE: 1. Panel color : Silver (General) / Bordeaux, Black Optional accessory (for Russia only). 2. Humidification amount changes in accordance with indoor and outdoor temperature and humidity. Measurement condition : 20°C (temperature), 30% (humidity) (JEM1426) 3. Operating sound levels are the average of values measured at 1m away from the front, left, right, and top of the unit.
-
Page 10: Dimension
SiBE81-909 Specifications Dimension MCK75JVM-K · Required installation space (If installed on the floor) Air outlet grille Signal Transmitter ON / OFF button 500 or more 500 or more · Dimension of remote controller (ARC458A4) Dust sensor Odor sensor Handles Direction of a blow... -
Page 11: Wiring Diagram
Specifications SiBE81-909 Wiring Diagram MCK75JVM-K Note: 1. S, CN SHOWS A CONNECTOR. 2. SYMBOLS SHOWS AS FOLLOWS H37P H36P H38P H39P : RED : BLACK H30P H31P H24P H44P H29P H35P H28P H34P H27P H33P H26P H32P H25P H43P H42P... -
Page 12: Packaging Drawing
SiBE81-909 Specifications Packaging Drawing Deodrizing cartridge pack Wireless remote controller ASSY Power supply code Pleats filter VIEW A Accesory bag ASSY Body Product cover C : 2P241869A Humidifying Air Purifier... -
Page 13: Operation Manual
Operation Manual SiBE81-909 5. Operation Manual Safety Precautions Humidifying Air Purifier... - Page 14 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 15 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 16 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 17: Names And Operation Of Each Part
Operation Manual SiBE81-909 Names and Operation of Each Part Humidifying Air Purifier... - Page 18 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 19 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 20 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 21 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 22 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 23: Sensitivity Settings Of The Dust Sensor
Operation Manual SiBE81-909 Sensitivity Settings of the Dust Sensor Humidifying Air Purifier... -
Page 24: Installation
SiBE81-909 Operation Manual Installation Humidifying Air Purifier... -
Page 25: Preparation Of Remote Controller
Operation Manual SiBE81-909 Preparation of Remote Controller Humidifying Air Purifier... -
Page 26: Attach The Filter
SiBE81-909 Operation Manual Attach the Filter Humidifying Air Purifier... -
Page 27: Water Tank Preparations
Operation Manual SiBE81-909 Water Tank Preparations Humidifying Air Purifier... - Page 28 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 29: Air Purifying Operation
Operation Manual SiBE81-909 Air Purifying Operation Humidifying Air Purifier... -
Page 30: Humidify And Air Purifying Operations
SiBE81-909 Operation Manual Humidify and Air Purifying Operations Humidifying Air Purifier... -
Page 31: How To Operate With Remote Controller
Operation Manual SiBE81-909 5.10 How to Operate with Remote Controller Humidifying Air Purifier... - Page 32 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 33: How To Use The Recyclable Deodorizing Cartridge
Operation Manual SiBE81-909 5.11 How to Use the Recyclable Deodorizing Cartridge Humidifying Air Purifier... - Page 34 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 35: Quick Reference Table Of Maintenance
Operation Manual SiBE81-909 5.12 Quick Reference Table of Maintenance Humidifying Air Purifier... - Page 36 SiBE81-909 Operation Manual Humidifying Air Purifier...
-
Page 37: Care And Cleaning
Operation Manual SiBE81-909 5.13 Care and Cleaning Humidifying Air Purifier... - Page 38 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 39 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 40 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 41 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 42 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 43 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 44 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 45 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 46 SiBE81-909 Operation Manual Humidifying Air Purifier...
- Page 47 Operation Manual SiBE81-909 Humidifying Air Purifier...
- Page 48 SiBE81-909 Operation Manual 3P234570-1 Humidifying Air Purifier...
-
Page 49: Optional Accessories
Optional Accessories SiBE81-909 6. Optional Accessories Dimensions 6.1.1 Pleated Filter KAC998A4E Specifications Model KAC998A4E Item Material Non-woven fabric (electrostatic) Quantity Notes: 1. Replacement guideline: Every year (for about 7 years in total) 2. Appearance color: White (front), blue (back) 26 pleats ± 1pleat... - Page 50 SiBE81-909 Optional Accessories 6.1.3 Front Panel (for Russia) BCK75J-BD Specifications Model BCK75J-BD Color and Bordeaux: 1 FRONT PANEL (OPTION) Quantity Black: 1 Bordeaux or Black Black 46.5 C:3D063742 Humidifying Air Purifier...
-
Page 51: Troubleshooting
Troubleshooting SiBE81-909 7. Troubleshooting Basic Inspection (1) Is the connector for the PCB plugged in? Or is there any poor connection? (2) Is the wire harness broken? It is not malfunction. Lighting UNIT1 Plasma ionizer UNIT2 Streamer unit Clean as above. - Page 52 SiBE81-909 Troubleshooting Check lamp Humidifying Air Purifier...
- Page 53 Troubleshooting SiBE81-909 It may be malfunction. Humidifying Air Purifier...
-
Page 54: Check Before Requesting Servicing
SiBE81-909 Troubleshooting Check Before Requesting Servicing Humidifying Air Purifier... - Page 55 Troubleshooting SiBE81-909 Humidifying Air Purifier...
- Page 56 SiBE81-909 Troubleshooting Humidifying Air Purifier...
-
Page 57: Frequently Asked Questions
Troubleshooting SiBE81-909 Frequently Asked Questions Humidifying Air Purifier... -
Page 58: Troubleshooting
SiBE81-909 Troubleshooting Troubleshooting 7.4.1 Equipment does not operate, or operation lamps does not light. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting MCK75JVM-K Diagnosis Remedy Plug in the power Is the power cord plugged in? cord. - Page 59 Troubleshooting SiBE81-909 7.4.2 The water supply lamp blinks. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MCK75JVM-K Set the humidifying Is the humidifying tray removed? tray.
- Page 60 SiBE81-909 Troubleshooting 7.4.3 The odor / dust sensor lamp keeps lighting red. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MCK75JVM-K <When the odor sensor is lighting red:>...
- Page 61 Troubleshooting SiBE81-909 7.4.4 DC fan locks. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting MCK75JVM-K Diagnosis Remedy All 4 airflow rate indicators blink simultaneously. Disconnect the power...
- Page 62 SiBE81-909 Troubleshooting 7.4.5 The odor / dust / humidity sensor lamp does not light. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting MCK75JVM-K Diagnosis Remedy If the brightness This is not a failure.
- Page 63 Troubleshooting SiBE81-909 7.4.6 Humidity is not increased, or the humidity sensor lamp is not changed. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting MCK75JVM-K Diagnosis Remedy...
- Page 64 SiBE81-909 Troubleshooting 7.4.7 The power supply PCB or the operation PCB is at fault. Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting MCK75JVM-K Diagnosis Remedy The 3 OFF timer lamps simultaneously blink.
-
Page 65: Check
Troubleshooting SiBE81-909 Check 7.5.1 Checking the connection when the PCB is replaced. Check1 Perform the following checking procedure when replacing the PCB. Procedure Pressing [ON/OFF] button and [Humidify ON/OFF] button simultaneously, turn on the power. → The buzzer sounds and all lamps light. - Page 66 Specifications, designs and other content appearing in this brochure are current as of December 2008 but subject to change without notice. SiBE81-909 Printed in Japan 12/2008 B AK...
