Audio Submenu

Figure 25.
The
Audio
PCS or the internal Web pages for initial audio configuration (see
Page on page 96 for more audio configuration details and tips).
Audio Mute — Press the navigation buttons to globally mute or unmute audio output.
Audio Format — Press the navigation buttons to select the audio input format. Analog
inputs can only be set to
formats.
Audio Input Format Details
None
Analog
LPCM-2Ch
Multi-Ch
LPCM-2Ch Auto
Multi-Ch Auto
NOTE: Multi-channel audio does not include microphone inputs or audio processing
when it is sent to the output. It is also unaffected by volume control.
Audio Submenu (IN1608)
submenu allows users to adjust audio settings. Extron recommends using the
or
Analog None
Mutes audio for the selected input. Sets "No Audio" EDID.
Sets the selected input to analog. Sets "No Audio" EDID.
Sets the selected input to LPCM-2Ch audio.
Sets 2Ch audio EDID.
Sets the selected input to Multi-Ch audio.
Sets Multi-Ch audio EDID.
Sets the selected input to prioritize digital audio. Analog
audio is passed when digital is not present.
Sets 2Ch audio EDID.
Sets the selected input to prioritize digital audio. Analog
audio is passed when digital is not present.
Sets Multi-Ch audio EDID.
IN1606 and IN1608 Series Scaling Presentation Switcher • Operation
Audio Configuration
. All other inputs can accept all audio input
Inputs
All
All
3+
3+
3+
3+
