Command

Input Configuration Commands

Input video format
Set video format
View set format
Input EDID
Assign EDID to input
View assigned EDID
Save an output EDID to
custom slot
Export EDID file
Import EDID file
NOTES:
• EDID import and export commands use the device user file system to hold an EDID file. Use IP Link File
Manager (download IP Link File Manager from the Extron website) to move EDID files between a PC and
the device user file system.
• < > can optionally carry a full path name on the device user file system.
filename
• EDID files must have an file extension of .bin, carrying 128 or 256 bytes of binary data.
• Exporting a default EDID table (for an
being exported.
Input name
Write input name
View input name
NOTE: To clear an input name, enter a single space character for
default.
NOTES:
X!
= Input selection
X@
= Output selection
X#
= Input video format
X1$
= Input name (text label)
X6)
= EDID emulation
IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control
ASCII Command
(host to scaler)
X! X#
* \
X!
\
E X! X6) }
A * EDID
E X! }
A EDID
E X@ X6) }
S * EDID
E X6)
E ,<filename>EDID
E X6)
I ,<filename>EDID
X5(
value of 10 or greater) results in the HDMI LPCM-2Ch table
E X! X1$ }
, NI
E X! }
NI
1-6
= HDMI A (top connector)
1
= HDMI B (bottom connector)
2
= Out C
3
= RGB (default for inputs 1 and 2)
1
= YUV
2
= RGBcvS
3
= S-video
4
= composite
5
= HDMI (default for inputs 3 and higher)
6
Up to 16 characters
See the
Response
(scaler to host)
X! X#]
Typ *
X#]
X! X6)]
EdidA *
X6)]
X@ X6)]
EdidS *
} X6)]
EdidE
} X6)]
EdidI
X! X1$]
Nmi ,
X1$]
X1$
. This resets the input name to the
(IN1606) or (IN1608 Series)
1-8
X6)
definition on page 47.
Additional Description
X! X#
Set input to format .
View the video format.
X6) X!
Assign EDID to input
X!
View the EDID for input .
X@ X6)
Save output EDID to
( , , ).
3-8 201 202
X6)
Export ( , ,
1-92 201 202
EDID.
X6)
Import ( , , )
3-8 201 202
EDID.
X!
Rename input .
X!
View the name of input .
.
)
49
