Auto Memory — Press the navigation buttons to turn Auto Memory on or off for each
input. The scaler stores 32 auto memories per input, with input configuration and picture
control data for each video resolution. The default setting enables these memories to
automatically recall input and picture controls for previously applied signals. When auto
memories are disabled, the scaler treats every applied signal as a new source.
Auto Memory and Auto-Image Interaction
Auto Memory Auto-Image
On On
On (default) Off (default)
Off On
Off Off
Overscan — Press the navigation buttons to select the overscan value for each input
format. Choose between 0%, 2.5%, or 5%. Set default overscan mode through SIS
commands (see the Overscan mode
Overcan is specific to each input signal type. This feature zooms and crops SMPTE input
resolutions to mask edge effects and ancillary data that are common in broadcast signals.
When the overscan mode is not at 0%, an Auto-Image on a SMPTE input rate (NTSC, PAL,
SECAM, 480p, 576p, 720p, 1080i, 1080p, and 2K [2048x1080]) refers to the default input
lookup table values instead of performing a "true" auto image.
NOTE: Overscan is valid only on SMPTE input rates (NTSC, PAL, 480p, 576p, 720p,
1080i, 1080p, or 2K [2048x1080]) and is global for each video format.
Auto Switch — Press the navigation buttons to turn the auto switch mode on or off, and to
set the priority. The auto switch setting allows for basic, unmanaged, input switching based
on the presence of active input signals. Auto switch mode options are:
• Disabled (off)
• Setting priority to "high to low" (highest numbered active input to the lowest)
• Setting priority to "low to high" (lowest numbered active input to the highest)
Factory Reset — Press and hold the
The scaler retains the current firmware version, as well as communication and IP settings.
IN1606 and IN1608 Series Scaling Presentation Switcher • Operation
Information
"New" signals and rates not previously detected by the
scaler, are initially set up using default parameters, then
Auto-Image is automatically applied. The next time the signal
is detected, the values stored in the auto memory location
are applied.
"New" signals and rates not been previously detected by
the scaler, are set up using default parameters. If manual
input or picture settings are made to the input, an auto
memory location is created and recalled each time the input
is detected.
Each change in input sync, input switch, or power cycle
triggers an automatic Auto-Image. When auto memory is
disabled, each change in sync is treated as a new signal
and an automatic Auto-Image is triggered. Manual changes
made to the image and picture controls are lost each time a
new rate is detected.
Each change in input sync causes default values to be
applied. Manual changes made to the image and picture
controls are lost when a new rate is applied, a new input is
applied, or after a power cycle.
SIS commands on page 59).
button to reset the device to factory defaults.
Enter
37
