DAVFU/IGP Execute Form Mode
To use the DAVFU with the IGP-10 or IGP-11 in the Execute Form Mode, it must be loaded
while the IGP is in the Execute Form Mode. Consequently, the IGP must create and execute an
empty form prior to the DAVFU load routine. A typical procedure follows:
1.
Create an empty form using the IGP-10/-11 Special Function Control Character
(SFCC) and Create command. Do not create any form elements and do not use the forms
length parameter.
2.
End the Create Form Mode with the End command.
3.
Execute the form using the IGP-10/-11 Special Function Control Character (SFCC)
and Execute command. Do not use the form count or page parameters.
4.
Enter the DAVFU Start Load code.
5.
Enter the DAVFU channel assignments.
6.
Enter the DAVFU End Load code.
NOTE: Refer to the IGP-10/20/40 or IGP-11/21/41 User's Reference Manual for
forms creation and execution information
Vertical Format Units
Table 5-3. DAVFU Channel Instruction
PI LINE
8
1
X
1
X
1
X
1
X
1
X
1
X
1
X
1
X
1
X
1
X
1
X
1
X
X = don't care (1 or 0)
BITS OF DATA BYTE
7
6
5
4
3
X
X
0
0
0
X
X
0
0
0
X
X
0
0
0
X
X
0
0
0
X
X
0
0
1
X
X
0
0
1
X
X
0
0
1
X
X
0
0
1
X
X
0
1
0
X
X
0
1
0
X
X
0
1
0
X
X
0
1
0
2
1
0
0
0
1
1
0
1
1
0
0
0
1
1
0
1
1
0
0
0
1
1
0
1
1
5-5
