Control Panel Configuration Diagram
The Control Panel Configuration Diagram is a series of block diagrams that show the configu
ration menus and the parameters available within each menu. Boxes on the diagram represent
the message display; the message that appears on the display is printed inside the box. The let
ters outside the boxes and adjacent to the directional arrows represent control panel function
switches. When the indicated switch is pressed, the arrow leads to the displayed result of press
ing that switch. The symbols used on the Control Panel Configuration Diagram are shown in
Figure 3-5.
The diagram is presented in 3 levels, each level illustrating a particular set of parameter menus
and values. The relationships between the three levels are shown in Figure 3-6.
Level I - Print Format
Line Spacing
Print Mode
Forms Length
Level II - Main Configuration Menus
Ribbon Life
Character Set
Application Compatibility
Paper Format
Host Interface
Load Parameters
Save Parameters
Diagnostics
Level III - Configuration Menu Parameters
Printer Protocol
Buffer Size
Uppercase Select
Printer Select
Paper Advance Switch
Power-On State
Unidirectional
Auto Line Feed
Define CR Code
Define LF Code
VFU Select
Perforation Skip
3-14
Paper Empty
PMD Fault
Modified Plot
Slew Relative
Centronics Interface Parameters
Dataproducts Interface Parameters
Serial RS-232 Interface Parameters
Configuration Printout
Print Data In Hex Code
Printer Test 80 Column Paper
Printer Test 132 Column Paper
Print Statistics
Configuration
