Ready Line - A high true level from the printer indicating ac power and dc voltages are pre
sent, paper is loaded properly, and the printer is not in a check condition.
On Line - A high true level from the printer indicating the Ready Line is true and the ON
LINE switch on the control panel has been activated.
Data Request - A high true level from the printer to synchronize host data transmission with
printer timing.
Data Strobe - A high true pulse from the host to indicate that data is ready. The data strobe
remains high until the Data Request line goes false.
Data Lines - Eight high or low levels from the host that specify character data, plot data, or a
control code. Sensing Data Line 8 is controlled by printer configuration.
+5 Volt Test - +5 Vdc output for operating the Printronix test exerciser.
Paper Instruction (PI) - Optional high true level EVFU signal from the host with the same
timing as the data lines. Sensing the PI line is controlled by printer configuration.
Interface Verification - Two pins on the interface connector jumpered together to allow the
user to verify proper installation of the interface connector.
Data Line 1
Data Line 2
Data Line 3
Data Line 4
Data Line 5
Data Line 6
Data Line 7
Data Line 8
Paper Instr.
Data Strobe
IBOF
(Bottom of Form)
7-2
Connector Pin Assignments for Dataproducts
Interface with AMP Connector
INPUT SIGNALS
SIGNAL PIN
19
Return 3
20
Return 4
1
Return 2
41
Return 40
34
Return 18
43
Return 25
36
Return 35
28
Return 44
30
Return 14
38
Return 37
24,50
Return 8,32
Table 7-1.
OUTPUT SIGNALS
SIGNAL
Ready
Return
On Line
Return
Data Request
Return
+5 Volts
(Test Only)
I/F Verif.
Ground
Not Used
Pins not listed
are not connected
PIN
22
6
21
5
23
7
12
46,45
11, 27,
39
31
Interfaces
