PRINT MODE - Press this switch to display the current print mode. Subsequently pressing
this switch changes the print mode and updates the display through all of the available print
modes listed below. Each print mode has a variety of pitch selections ranging from 10 to 17
characters per inch (cpi). Print mode is a line-by-line attribute; different print modes (and
related pitch) can be used for different lines of the form but you cannot mix print modes on one
Operation

CONTROL PANEL

ON LINE
POWER
PAPER TOP OF
ADVANCE FORM
MESSAGE
DISPLAY
FORMS SET UP
FORMS SET
LENGTH T O F
PRINT FORMAT
LINE PRINT
SPACING MODE
CONFIG CONFIG
MENU VALUE
RUN/STOP CLEAR
TEST FAULT
Figure 2-3. Control Panel
2-5
