L-Acoustics kudo multi-mode wst Rigging Manual page 13

2. On each KUDO ® enclosure, adjust the K-LOUVER
3. On each KUDO ® enclosure, remove the 8 BLP.
4. On both sides of each KUDO
secure the front rigging point using the corresponding BLP.
5. Align all KUDO ® enclosure front rigging points (do not attach).
6. On both sides of each KUDO
pre-select angle).
Figure 9: Attaching the rear inter-enclosure BLP (angle selection and front rigging points are not secured)
KUDO_RM_ML_1.0
® panels (see the ''KUDO
®
enclosure, push forward the rotating arm tab (accessible in the handle pocket) and
Figure 8: Securing the front rigging points
® enclosure, push out the rotating arm and attach the rear inter-enclosure BLP (do not
w w w . l - a c o u s t i c s . c o m
® '' user manual).
EN
11 en
