INTRODUCTION

3.1

Welcome to L-ACOUSTICS

Thank you for purchasing the L-ACOUSTICS
This manual contains essential information on the L-ACOUSTICS
carefully in order to make familiar with these procedures.
As part of a continuous evolution of techniques and standards, L-ACOUSTICS
change the specifications of the product and the content of this manual without prior notice. Please check
the L-ACOUSTICS ® internet website @
If the product requires repair or if information about the warranty is needed, please contact an approved
®
L-ACOUSTICS distributor. In order to obtain the address of the nearest distributor go to the internet website
@ www.l-acoustics.com.
3.2

Unpacking

Carefully open the shipping carton and check the product for any noticeable damage. Each L-ACOUSTICS
tested and inspected before leaving the factory and should arrive in perfect condition.
If found to be damaged, notify the shipping company or the distributor immediately. Only the consignee may initiate a
claim with the carrier for damage incurred during shipping. Be sure to save the carton and packing materials for the
carrier's inspection.
The KBUMP package comprises the following elements:
•
One L-ACOUSTICS
•
Two shackles fitted with 22 mm/0.87 in. screw pin, hereafter designated as ''22-shackles''.
The KLIFT package comprises the following elements:
•
One L-ACOUSTICS
• One shackle fitted with 18 mm/0.71 in. screw pin, hereafter designated as ''18-shackle''.
The KJACK package comprises the following elements:
• Two wheel-handled threaded rods.
• Two U-brackets attached to support base.
KBUMP
KUDO_RM_ML_1.0
®
®
KUDO ® Multi-Mode WST
www.l-acoustics.com
® KBUMP rigging structure with 4 ball locking pins hereafter designated as ''BLP''.
®
KLIFT rigging bar.
Figure 1: KUDO ®
w w w . l - a c o u s t i c s . c o m
®
Enclosure.
® KUDO ® rigging procedures. Read this manual
on a regular basis for latest update.
KLIFT
rigging components
® reserves the right to
® product is
KJACK
5 en
