KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
6

INSTALLATION

6.1

Flying a vertical line source array (using KBUMP)

Before installation, in order to position and correctly place the array the user should use L-ACOUSTICS
SOUNDVISION software to determine:
• Correct hole position of the shackles on the KBUMP
• Number of KUDO
• Inter-angles between KUDO
• Check of the system's mechanical conformity
!
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
that safe system setup safety limits apply (see section ''Mechanical Data'' in the SOUNDVISION
software).
WARNING
The rigging method to fly the KUDO
the next is done by using fully integrated components unique to each KUDO
fastening accessory. Each KUDO
rigging points that lock into the device below, using ball locking pins (BLP).
The following procedures describe how to fly a vertical KUDO
6.1.1
Assembling the KUDO
!
All along the following procedure systematically ensure that each BLP is correctly secured by pulling
on it, and that screw pin is correctly secured on each shackle anchor.
WARNING
1. Line up the KBUMP structure and all KUDO
Figure 7: Lining up the KUDO
KUDO_RM_ML_1.0
®
SYSTEM
®
enclosures
®
enclosures
®
system comprises the elements KBUMP and KUDO
®
enclosure incorporates two rotating arms that lock into the device above, and four
®
enclosures and the KBUMP structure
®
enclosures at the rigging location.
®
enclosures and the KBUMP structure
w w w . l - a c o u s t i c s . c o m
®
. There is no need for any other external
®
line source array, and how to disassemble it.
®
®
. Attaching one element to
10 en
