L-Acoustics kudo multi-mode wst Rigging Manual page 14

®
KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
7. On both sides of the first KUDO
8. On the KBUMP structure, ensure that the 4 BLP are located in their inner storage holes.
9. a. Place the KBUMP in position by aligning both stop tabs with the top KUDO
!
WARNING
b. Attach the 4 BLP in the outer storage holes so as to secure the KBUMP to the top KUDO
10. Attach the 22-shackles according to the specifications detailed in appendix 9.1.
Figure 11: Securing the KBUMP to the first KUDO
KUDO_RM_ML_1.0
®
SYSTEM
® enclosure, select the 5° angle (the top enclosure will be parallel to the KBUMP).
Figure 10: First enclosure 5° angle setting
The KBUMP should be installed with the serial number tag oriented towards the
rear of the array.
Support the KBUMP in order to prevent it from falling.
w w w . l - a c o u s t i c s . c o m
® enclosure's front rigging points.
Outer storage hole
Inner storage hole
Stop tab
® enclosure, positioning the shackles
®
enclosure.
12 en
