KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
8

SPECIFICATIONS

Reference
Dimensions (L x H x P)
Weight
Setup safety limits 1
Flown vertical array
Stacked vertical array
Material
Complementary accessories KJACK wheel-handled threaded rods for stacking a vertical array (available as an option)
1 Installation safety limits are specified in the SOUNDVISION software which is designed to help with L-ACOUSTICS
Reference
Dimensions (L x H x P)
Weight
Setup safety limits 1
Flown horizontal array
Material
Complementary accessory
1
Installation safety limits are specified in the SOUNDVISION software which is designed to help with L-ACOUSTICS
KUDO_RM_ML_1.0
®
SYSTEM
KBUMP
866 x 100 x 1000 mm 34.1 x 3.9 x 39.4 in.
44 kg 97 lb.
Maximum of 21 KUDO ® enclosures per KBUMP
Maximum of 6 KUDO ® enclosures per KBUMP and pair of KJACK
black epoxy-coated steel
2 shackles with 22 mm/0.87 in. screw pin
KLIFT
508 x 130 x 34 mm
2 kg 4.4 lb.
Maximum of 6 KUDO ®
black epoxy-coated steel
1 shackle with 18 mm/0.71 in. screw pin
w w w . l - a c o u s t i c s . c o m
20 x 5.1 x 1.3 in.
enclosures per KLIFT
® product implementation.
®
product implementation.
28 en
