4 KUDO SYSTEM
®
®
The L-ACOUSTICS KBUMP structure and the KLIFT and KJACK accessories are dedicated to fly and stack the
®
KUDO system.
The system approach developed by L-ACOUSTICS
advantage of the possible configurations and optimize the system. The main components of the system are:
KUDO ®
KBUMP
KJACK
KLIFT
KPLA-2, KCOV
SB118, SB28
LA8
SOUNDVISION
LA NETWORK MANAGER
KUDO ®
LA8
Each system configuration should first be modeled using the L-ACOUSTICS
that safe system setup safety limits apply. A detailed description on the use of the SOUNDVISION software is beyond
the scope of this manual. Please refer to the appropriate documentation, also available on the L-ACOUSTICS
website @ www.l-acoustics.com.
KUDO_RM_ML_1.0
®
SYSTEM
® for KUDO
Full range active 3-way loudspeaker enclosure
Rigging structure to fly or stack a KUDO
Rigging accessories (x2) used in conjunction with KBUMP to stack KUDO
Rigging accessory to fly a KUDO
Removable front dolly board and protective cover to ship the KUDO
Subwoofer enclosures for extended low frequency response
Dedicated amplified controller
Acoustical and mechanical modeling software
Remote control software
KPLA-2
SOUNDVISION
Figure 2: KUDO ® system components
