L-Acoustics kudo multi-mode wst Rigging Manual page 10

®
KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
Figure 4: KBUMP and KJACK elements for stacking a KUDO
KBUMP can also be used as a horizontal or tilted ground stacking platform using two complimentary KJACK accessories
(Figure 4).
A maximum of 6 KUDO
!
When KBUMP is used with the complimentary KJACK accessories so as to form a tilted platform, the
following limitations apply:
WARNING
K-BUMP
site angle
Maximum
number
of
KUDO
And as a general guideline, always refer to the mechanical data and warning indications provided in
SOUNDVISION to verify that safe system setup safety limits apply (see section ''Mechanical Data'' in
the SOUNDVISION software).
Ensure that KBUMP is physically secured to the stacking platform or subwoofer stack using ratchet
straps or any applicable materials.
KUDO_RM_ML_1.0
®
SYSTEM
® can be stacked onto a horizontally configured KBUMP (site angle set at 0°).
[-10°,-9°[ [-9°,-7°[
3 4
®
w w w . l - a c o u s t i c s . c o m
[-7°,-6°[ [-6°,-1.5°] [1.5°,2°[
5 6
®
array
[2°,9°[ [9°,10°]
6 5 4
8 en
