7. System parts and rigging inspection
!
All system components must be inspected before use, in order to detect any possible defects.
Please refer to the "Care and maintenance" section of this manual as well as any other manuals
pertaining to the system for a detailed description of the inspection procedure.
Any part showing any sign of defect must immediately be put aside and withdrawn from use to be
WARNING
inspected by qualified service personnel.
!
8. Additional rigging equipment
L-ACOUSTICS
manufactured by L-ACOUSTICS
It is the user's responsibility to ensure that the Working Load Limit (WLL) of all additional
hardware rigging accessories is greater than the total weight of the loudspeaker assembly in use.
WARNING
!
9. Suspension points
It is the user's responsibility to ensure that the Working Load Limit (WLL) of the suspension
points and/or chain hoists is greater than the total weight of the loudspeaker assembly in use.
WARNING
!
10. System load capacity and setup safety limits
Load capacity and setup safety limits when flying or stacking a loudspeaker assembly should be
strictly followed according to the instructions outlined in this manual.
Always refer to the mechanical data and warning indications provided in SOUNDVISION to
verify that safe system setup safety limits apply.
WARNING
!
11. Local regulations
Some countries require higher Ultimate Strength Safety Factors and specific rigging approvals. It
is the user responsibility to ensure that any overhead suspension of L-ACOUSTICS
has been made in accordance with all applicable local regulations.
As a general rule, L-ACOUSTICS
WARNING
!
12. Flying a loudspeaker assembly
Always ensure that nobody is standing underneath the loudspeaker assembly when it is being
raised. As the system is being raised check each individual component to make sure that it is
securely fastened to the component above. Never leave the system unattended during the
installation process.
WARNING
13. Ground stacking a loudspeaker assembly
!
Do not ground stack the system on uneven ground or platform.
If the system is ground stacked on a structure, platform, or stage always check that it can
support the total weight of the system.
Secure the system to the structure, platform, or stage using ratchet straps or any other
WARNING
applicable devices.
!
14. Dynamic load
When a loudspeaker assembly is deployed in an open air environment wind effect should be
taken into account. Wind can produce dynamic stress to the rigging components and suspension
points. If the wind force exceeds 6 bft. (Beaufort scale) it is highly recommended to lower down
and/or secure the loudspeaker assembly.
WARNING
KUDO_RM_ML_1.0
®
SYSTEM
®
is not responsible for any rigging equipment and accessories that are not
®
.
® recommends the use of safety steel at all times.
