ELEVATOR CONTROL HORN.
Install the elevator control horn using the
same method as with the aileron control
horns.
3x35mm.
CONTROL HORN M3
.
Aluminum Washer
Horizontal
Stabilizer.
.
Aluminum Washer
Horizontal
Stabilizer.
16mm
.
Elevator control horn
RUDDER CONTROL HORN.
Rudder control horn:
Using the same techniques used aileron
control horn. See picture below.
www.seagullmodels.com
2 sets.
.
Epoxy
Elevator.
.
M3 LOCK NUT
Epoxy.
.
3x45mm.
CONTROL HORN
.
M3 SCREW
.
ALUMINUM WASHER
FUSELAGE
.
ALUMINUM WASHER
Fuselage.
18mm
.
Rudder control horn.
2 sets.
EPOXY.
Rudder
.
M3 LOCK NUT
EPOXY.
Rudder.
5
