CAP 232
"Graphics and specifications may change without notice".
Specifications
Wing span-------------------------------------57.1in -------------------------------- 145cm.
Wing area------------------------------------604.5 sq.in ---------------------- 39 sq.dm.
Approximate flying weight-----------------7.5 lbs-------------------------------- 3.4kg.
Length-----------------------------------------51.7in-------------------------------131.4cm.
Recommended engine size------------ .46 - .55 cu.in-------------------- 2-stroke.
ELECTRIC CONVERSION : OPTIONAL.
Radio System required 4 channels with 6 digital servos.
Flying skill level Intermediate/advanced.
Kit features.
•
Ready-made—minimal assembly & finishing required.
•
Ready-covered covering.
•
Photo-illustrated step-by-step Assembly Manual.
Made in Vietnam.
ASSEMBLY MANUAL
.72 - .82 cu.in -------------------- 4-stroke.
MS: SEA 97
