Seagull Models CAP 232 Assembly Manual

Hide thumbs Also See for CAP 232:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Assembly Manual
CAP 232
"Graphics and specfications may change without notice".
Specifications
Wingspan-------------------------------------65 in---------------------------------- 165cm.
Wing area------------------------------------782.8 sq.in-------------------- 50.5 sq.dm.
Approximate flying weight----------------8.8 - 10.6 lbs--------------------4 - 4.8kg.
Length----------------------------------------- 58.8in------------------------------149.4cm.
Recommended engine size------------ .61 - .75 cu.in-------------------- 2-stroke.
Radio System required 4 channels with 6 servos
Flying skill level Intermediate/advanced.
Kit features.
•
Ready-made—minimal assembly & finishing required.
•
Ready-covered covering.
•
Photo-illustrated step-by-step Assembly Manual.
Made in Vietnam.
ASSEMBLY MANUAL
.82 - 1.0 cu.in ---------------------4-stroke.
MS: SEA 91

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAP 232 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seagull Models CAP 232

Summary of Contents for Seagull Models CAP 232

  • Page 1 CAP 232 MS: SEA 91 ASSEMBLY MANUAL “Graphics and specfications may change without notice”. Specifications Wingspan-------------------------------------65 in---------------------------------- 165cm. Wing area------------------------------------782.8 sq.in-------------------- 50.5 sq.dm. Approximate flying weight----------------8.8 - 10.6 lbs--------------------4 - 4.8kg. Length----------------------------------------- 58.8in------------------------------149.4cm. Recommended engine size------------ .61 - .75 cu.in-------------------- 2-stroke.
