AT-6 TEXAN _
CODE SEA 110
ELEVATOR CONTROL HORN.
Install the elevator control horn using the
same method as with the aileron control
horns.
3x30mm.
CONTROL HORN M3
Aluminum Washer
Aluminum Washer
Horizontal
Stabilizer
.
.
18mm
6
.
2 sets.
.
.
Epoxy
.
.
M3 LOCK NUT
.
Epoxy
Elevator control horn.
RUDDER CONTROL HORN.
Rudder control horn:
Using the same techniques used aileron
control horn. See picture below.
3x30mm.
CONTROL HORN
.
M3 SCREW
.
ALUMINUM WASHER
.
ALUMINUM WASHER
Fuselage
.
.
18mm
1 sets.
EPOXY.
.
M3 LOCK NUT
EPOXY.
Rudder
.
