2.6.3 Connecting a Single Keypad to a Matrix 832+
Tamper terminals
of ICON Keypad
NOTE: After adding or removing equipment from the system, use engineers function 754 to scan for
all devices on the Matrix bus.
RINS918-6
ICON
Keypad
LCD
Keypad
Matrix 424, 832, 832+ Installation Manual
MATRIX 832+ PCB
KEYPAD 1
(ID1)
OK
Page 13
