Matrix 424, 832, 832+ Installation Manual
4. SYSTEM OVERVIEW & TECHNICAL SPECIFICATIONS
This manual supports the following panels: Matrix 424, Matrix 832 and Matrix 832+.

4.1 System Overview

4.1.1 Zones

Zones on Main Board
Zone Expander (On Board)
Zone Expander MX-RIX
Zone Expander
MX-RIX8DW
Maximum Zones
Capacity
Zone Configurations
Zone Types
Zone Attributes
4.1.2 Programmable Outputs (PGM)
PGM Outputs On-Board
Output Expander MX-ROX
Maximum PGM Outputs Capacity
PGM Not Used
Options PIR Remote LED enable (E-)
PIR Latch Memory (C+)
RKP Controlled
Follow Arm/Disarm
Follow Zone
Follow Tel Line Fail
Follow Kiss Off
Shock/Fire Sensor Reset
Follow Strobe
Follow Fire Alarm
Follow PA Alarm
Follow Confirmed Alarm
Page 44
Matrix 424 4 fully programmable zones
Matrix 832/832+ 8 fully programmable zones
8 fully programmable zones on local plug in expander
Matrix 424 8 fully programmable zones on remote expander
Matrix 832/832+ 8 fully programmable zones on remote expander
Matrix 424 8 fully programmable zones on remote expander
Matrix 832/832+ 8 fully programmable zones on remote expander
Matrix 424 28 zones using 3 x zone expanders
Matrix 832/832+ 32 zones using 3 x zone expanders (64 with zone doubling)
Normally Closed
DEOL – 2 end of line resistors per zone
Entry/Exit, Access, Immediate, Omit (Bypass), Fire, PA, 24Hr,
Key Box, Shunt Keypad, Tamper, Latched Key, Momentary Key,
Unused, Medical, Arm
Chime, Test, Mask, Double knock, Normally open
PGM 1 – NO/NC
PGM 2 – NO/NC (832+), Active High / Active Low (424/832)
PGM 3 – Active High / Active Low
PGM 4 – Active High / Active Low
8 open collector/relay expander – installable remotely on keypad bus
12 outputs using output expander
Twin Alert
Follow Entry Exit
Follow Digi Com - Fire Alarm
Follow Digi Com - PA Alarm
Follow Digi Com - Intruder Alarm
Follow Digi Com - Open/Close
Follow Digi Com - Spare Alarm
Follow Digi Com - Medical Alarm
Follow Digi Com - Confirm Alarm
Follow Digi Com - Omits (Bypass)
Follow Hidden Display
Follow Mains Fail
Follow Battery Low
Follow Battery Faults
Follow Duress
Follow Disarmed
Follow System Faults
Momentary Burglary
Follow Momentary 24H
Follow Momentary FIRE
Follow Momentary MEDICAL
Follow Momentary PA
Follow Momentary TAMPER
Follow Momentary DURESS
Follow Momentary COMFAIL
Follow Momentary RKPFAIL
RINS918-6
